AGM/GEL Battery Charger
Max charging current: 6A.
Rated input voltage(AC): 90-250V.
LCD real-time display.
Battery repair function.
Applicable for Lead-acid/GEL/AGM/Maintenance-free battery.
This charger micro controller MCU intelligent control and management of battery charging process,the battery is full automatically stop charging.
It adopts efficient three-phase(constant current phase,constant voltage phase,floating charging phase) digital management of charging ways.
With battery-line detection, short circuit, overcharge, over voltage and reverse polarity protection and other functions.
The detailed charging indicator or LCD display shows charging process directly reflects,which facilitates users to quickly understand the current state of the battery.
Function parameters | |
Model | FON-1206Y |
Maximum charging current | 6A |
Applicable battery voltage(DC) | 12V |
Rated Input Voltage(AC) | 90V-250V |
Rated Frequency | 47-63Hz |
Full Load Efficiency | ≥87% |
Mechanical Shock and Quake-proof Degree | SAEJ1378 |
Temperature Range | -20~+90℃ |
Product size(ctn) | 62.5*44.5*36.5cm |
Weight(KG) | 19.68KG/CTN |
