Solar Charge Controller
Clock timing function.
Built-in two 5V 2A/1A USB interfaces.
Extreme Low Power Consumption.
Built-in IR self-learning infrared remote control to turn the DC loads on and off.
LCD Display with backlight.
Adjustable charging voltage(Low:14.2V,Default:14.5V,High:15.2V).
Light control mode,Time control mode.
Reverse protection,short circuit protection.
Designed for 12V/24V solar power system.
Hanging style design makes it convenient to install.
Available in 10A/20A/30A/40A.
Simple options,automatic memory retention of users' settings.
Five protection to ensure the safe, including charging over voltage / charging flow / over-current / load load short circuit / under-voltageprotection.
| Product Specification | |||
| Model | FT-C1210 | FT-C1220 | FT-C1230 |
| to adapt to the battery | 12V/24V,battery<16V:12V,Battery>18V:24V | ||
| Maximum charging voltage | 12V:18-24V Standard specifications solar panels(24V battery*2) | ||
| Maximum charging current | 10A | 20A | 30A |
| Maximum charging voltage | Low:14.2V,Default:14.5V,High:15.2V | ||
| The largest output current | 12A | 24A | 35A |
| Low voltage protection voltage | 10.5V(24 battery*2) | ||
| Low pressure recovery voltage | 12.5V(24 battery*2) | ||
| Load overload automatic recovery | 30S | ||
| Double USB output | 5V 2A/1A | ||
| Load relating to open time | 0-24 hours can choose | ||
| Infrared remote control distance | >5m | ||
| Pieces/CTN | 40pcs | 40pcs | 40pcs |
| Weight/CTN | 14.05kg | 14.3kg | 21kg |
| Dimensions/CTN | 52*27*40cm | 52*27*40cm | 54*27*44cm |
