Inverter With Charger
Built in 5V 1A USB charging interface.
Modified sine waveform output.
Inverter and charger can work independent noninterference.
Built-in 10A charger.
High conversion efficiency, smart soft start function.
Input and output are completely independent.
Smart, light,and portable,designed for home use.
Universal socket, suitable for all kinds of plugs.
Applicable for resistive loads.
High-procision voltage stability and Aerospace-grade silence technology.
Cooler of fan and working status are intellectually controlled by MCU, which mostly prolongs its service life and helps to save the power consumption.
Multiple safe protections include overload/overvoltage/low voltage/high temperature,output short circuit and reverse connecting protection..
Product Specification | ||
Model | FA-1000C | |
External battery | 12V 20AH~100AH | |
AC input | Voltage | AC 110~230V |
Frequency | 50Hz±10% | |
DC input | Voltage | DC12V |
Low voltage protection | DC10V | |
Over voltage protection | DC16V | |
AC Output | Voltage | AC 230V |
Output power | 550W | |
Frequency | 50±0.5Hz | |
Waveform | Modified sine wave | |
Efficiency | ≥85% | |
Charging | Charge current | <10A |
Charge efficiency | 90% | |
Protect | Input reverse polarity/Undervoltage/Overload/Input over-voltage/Short circuit/Over-temperature protection | |
Environment | Noise | ≤45db |
Temperature | 0℃±40℃ | |
Humidity | 10%±90% | |
Dimensions | 267x95x55cm | |
N.W | 0.9kg |
