Modified Sine Wave Inverter
Smart, light,and portable,designed for home use
3000va DC 12V to AC 220V power inverter
Modified/Square waveform output
USB Charging Output 5V 1A
Low standby power cost
High coversion effeciency(>70%),smart soft start function
Universal socket, suitable for all kinds of plugs
Intelligent cooling fan controlled by the workload
Input and output are completely independent
Applicable for resistive loads
High-procision voltage stability technology&Aerospace-grade silence technology
Multiple safe protections are designed,including overload/overvoltage/low voltage/high temperature,and short circuit protection
Product Specification | ||||||
Model |
FA- 350A |
FA- 500A |
FA- 1000A |
FA- 1500A |
FA- 2000A |
FA- 3000A |
Output Voltage | 220VAC | |||||
Output Waveform | Modified sine waveform | |||||
Rated Power | 200W | 350W | 600W | 700W | 800W | 900W |
Peak Power | 350W | 500W | 1000W | 1500W | 2000W | 3000W |
Working voltage | DC12V | |||||
Frequency | 50Hz | |||||
No-load Current | <0.5A | |||||
Voltage Range | 10.5-15V | |||||
Alarm Voltage | 10.5-15V | |||||
Low-voltage protection | 10.5V | |||||
Over voltage protection | 15V | |||||
Efficiency | 70%~80% | |||||
SIZE/CTN | 39*30*34cm | 39*30*34cm | 46*30*33cm | 46*30*33cm | 54*30*33cm | 54*30*33cm |
G.W./CTN | 14.26kg | 14.26kg | 16.94kg | 16.94kg | 23.32kg | 18.3kg |
Packing/CTN | 20PCS | 12PCS |
