FTB-2000B

Sunchonglic 24V to 110V 60Hz 2000w 2000watt inversor modified sine wave inverter

FTB-2000B

Modified Inverter 110V

Features:

24V 110V 60Hz 2000w off grid modified sine wave power inverter.

It is very portable and easy to use,no matter it connect to a car or other 24V battery.

It could provide home applicance with reliable AC power such as TV,DVD players and electric tools,etc.

Modified sine waveform output.

Built in 5V 2A USB charging interface.

Conversion efficiency is up to 90%.

Low leakage current, less than 90μA.

Intelligent speed regulation fan.

Multiple protections: short circuit protection/overheat protection/overload protection/input overvoltage protection/input under voltage protection.

Applications: Vehicles, yachts, home appliances, office and portable equipment,etc.

INQUIRE NOW

SEND ENQUIRY

  X
Submit

Specifications

Model FTB-2000B
Input Rated battery voltage 24V
Rated current 80A
No load current ≤700mA
Efficiency ≥90%
Battery type Lead-acid battery
AC output Rated Power 1800W
AC voltage 110 VAC
Frequency 60Hz
Waveform Modified sine wave
Input Protection Battery under voltage shutdowm 20V±0.5V
Battery under voltage recovery 22V±0.5V
Battery over voltage protection 31V±0.5V
Battery over voltage recovery 30V±0.5V
Output Protection Output short circuit Protection: turn off output and resume after restart
Over load Protection: output power>1800W, turn off output and resume after restart
Over heat Internal temperature >90℃,turn off output
'Internal temperature <80℃,automatically resume output
Environment Working temperature -40~+70℃
Working humidity 20%~95%RH
Storage temperature/humidity -40~+85℃, 10%~95%RH
Others Dimension 256x155x85mm

Product Photos
